Port of mini prolog II to Ada-83

Software from the 80s (educational).

Description

This is a port to Ada-83, with adaptations, of the mini Prolog II described in the book “L’anatomie de Prolog”. This book was published by Michel Van Caneghem in 1986.

I made this port around 1988 or 1989. The underlying data model and the parser of this Ada port are derived from muLISP/muSIMP, that I was studying during the same period.

The garbage collector is not implemented. When the memory is full, c’est fini.

The syntax is Edinburgh, not Marseille.

History

Alain Colmerauer site.

M. Van Caneghem. L’Anatomie de Prolog II, thèse d’Etat, October 1984. Supervised by Alain Colmerauer.

The site Prolog Héritage gives access to the documentation and Windows executables of PrologI, PrologII, PrologIII and PrologIV.

Source files

Encoded UTF-8.

In french.

HTML with cross-references.

Build

With GNAT Ada:

gprclean -r -P/local/prolog/prolog2/prolog2.gpr
gprbuild -d -P/local/prolog/prolog2/prolog2.gpr

Build output:

gcc -c -gnatQ -O3 prolog.adb
gcc -c -gnatQ -O3 interpreteur_prolog.adb
gcc -c -gnatQ -O3 es_prolog.adb
gcc -c -gnatQ -O3 infos.adb
gcc -c -gnatQ -O3 int32_io.adb
gcc -c -gnatQ -O3 objets_prolog.adb
gprbind prolog.bexch
gnatbind prolog.ali
gcc -c b__prolog.adb
gcc prolog.o -o prolog

Primitives

answer(yes_no | first | all | X)

answer(yes_no).     % from now, display yes or no
answer(0).          % same as answer(yes_no)
answer(first).      % from now, display the first solution only
answer(1).          % same as answer(first)
answer(2).          % from now, display at most 2 solutions
answer(all).        % from now, display all the solutions
answer(X).          % current setting

args2(N, X, Item)

If N=0 then Item=length(X) otherwise Item=Nth item of X.

asserta(Fact), assert(Fact), assertz(Fact)

asserta(Fact) : insert fact at the begining of the predicate.

assert(Fact), assertz(Fact) : insert a fact at the end of the predicate.

?- assertz(city(lyon)).
yes
?- assertz(city(marseille)).
yes
?- asserta(city(angers)).
yes
?- asserta(city(amiens)).
yes
?- listing.
city(amiens).
city(angers).
city(lyon).
city(marseille).

yes
?- city(X).
[1] X = amiens
[2] X = angers
[3] X = lyon
[4] X = marseille
yes

display(X)

Display X, with the free variables denoted by numbers, the strings possibly surrounded by quotes.

?- X=Y, Y=f(X), Z=['text', 'more text', symbol, 100, (vector), Variable], display(X), nl, display(Y), nl, display(Z), nl.
f(_1)
f(_1)
[text, 'more text', symbol, 100, (vector), _4]
[1] X = f(*1), Y = f(*1), Z = [text, more text, symbol, 100, (vector), Variable], Variable = Variable
yes

length(X, Length)

Works for any type:

list_dlength(X, Length, Depth)

Deep length: count the number of leaf items at all levels, calculate the max depth.

Inside a list, [] is a leaf item, as () and any non-list item: length+=1, depth+=0.

A leaf item after (if any) is ignored (same rule than list_length).

The depth lets make a distinction between lists and non-lists.

list_dlength and list_length are equivalent when the list contains no sublist, or sublists with 0 or 1 item:

?- X=[], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [], LL = 0, DL = 0, DD = 1
yes
?- X=[a, b], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [a, b], LL = 2, DL = 2, DD = 1
yes
?- X=[a, b, [], []], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [a, b, [], []], LL = 4, DL = 4, DD = 1
yes
?- X=[a, [b], c], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [a, [b], c], LL = 3, DL = 3, DD = 2
yes
?- X=[a, [[b]], c], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [a, [[b]], c], LL = 3, DL = 3, DD = 3
yes

The length & depth of a non-list is 0 & 0.

?- list_dlength(x, L, D).
[1] L = 0, D = 0
yes
?- list_dlength(f(x), L, D).
[1] L = 0, D = 0
yes
?- list_dlength((a,b,c), L, D).
[1] L = 0, D = 0
yes

list_dlength and list_length are different when the list contains sublists with more than 1 item:

?- X=[a, [b1, b2], c], list_length(X, LL), list_dlength(X, DL, DD).
[1] X = [a, [b1, b2], c], LL = 3, DL = 4, DD = 2
yes

echo(off | on | X)

echo(off).      % from now, don't display the lines read from input
echo(on).       % from now, display the lines read from input
echo(X).        % current setting

freezeA(Var, Goal)

Used by the primitive freeze :

halt

Quit the interpreter.

integer_sequence(From, To, Step, N)

Generate a sequence of integers.

Ascending:

?- integer_sequence(0, 10, 2, N).
[1] N = 0
[2] N = 2
[3] N = 4
[4] N = 6
[5] N = 8
[6] N = 10
yes

?- integer_sequence(0, infinity, 1000, N).
[1] N = 0
[2] N = 1000
[3] N = 2000
...
[503] N = 502000
[504] N = 503000
[505] N = 504000
Not enough memory for substitutions
Aborting current evaluation...

Descending:

?- integer_sequence(0, -10, -3, N).
[1] N = 0
[2] N = -3
[3] N = -6
[4] N = -9
yes

?- integer_sequence(0, -infinity, -1000, N).
[1] N = 0
[2] N = -1000
[3] N = -2000
...
[503] N = -502000
[504] N = -503000
[505] N = -504000
Not enough memory for substitutions
Aborting current evaluation...

is(Var, Expression)

Evaluate the Expression and binds Var to the result.

list_length(X, Length)

Get/Check the length of a list

?- list_length([a,b,c], 3).
yes
?- list_length([a,b,c], L).
[1] L = 3
yes

or generate a list of a given length

?- list_length(L, 3).
[1] L = [_9, _14, _19]
yes

or generate all the lists from 0 to infinity length.

?- answer(10).
yes
?- list_length(List, Length).
[1] List = [], Length = 0
[2] List = [_8], Length = 1
[3] List = [_8, _13], Length = 2
[4] List = [_8, _13, _18], Length = 3
[5] List = [_8, _13, _18, _23], Length = 4
[6] List = [_8, _13, _18, _23, _28], Length = 5
[7] List = [_8, _13, _18, _23, _28, _33], Length = 6
[8] List = [_8, _13, _18, _23, _28, _33, _38], Length = 7
[9] List = [_8, _13, _18, _23, _28, _33, _38, _43], Length = 8
[10] List = [_8, _13, _18, _23, _28, _33, _38, _43, _48], Length = 9
...
yes

The length of a non-list is 0.

?- list_length(x, L).
[1] L = 0
yes
?- list_length(f(x), L).
[1] L = 0
yes
?- list_length((a,b,c), L).
[1] L = 0
yes

listing, listing(X)

listing: display the rules of all the user-defined predicates.

listing(X): display the rules of the predicate X.

nl

Display a newline.

reduce(X, Y, V)

Used by the primitive dif :

statistics

Display statistics.

Mot_Valeur'Size =  4
Mot'Size =         8

------------------------------------------------------------------------------
|                                    |TAILLE |POSITION|COURANT| MAXI |MEMOIRE|
|                                    |ELEMENT|COURANTE|  MAXI |ALLOUE|ALLOUEE|
------------------------------------------------------------------------------
| Zone des symboles                  |     24|      92|.......|  2000|  48000|
| Pnames associes aux symboles       |      1|     360|.......| 32767|  32767|
| Table des hash-codes pour symboles |      1|........|.......|   256|    256|
| Table association variable-symbole |      1|........|.......|   100|    100|
| Zone des doublets, FIRST           |      8|     644|.......| 16300| 130400|
| Zone des doublets, REST            |      8|     644|.......| 16300| 130400|
| Table des operateurs               |     21|........|.......|   100|   2100|
| Table des tokens                   |      3|........|.......|    17|     51|
| Pile des substitutions             |     16|       3|     65|  8100| 129600|
| Pile de sauvegarde                 |     20|       1|      3|  5000| 100000|
| Pile des noms de variables         |      8|       1|      5|   200|   1600|
| Pile des equations                 |     24|       1|     84|  5000| 120000|
| Pile des etapes                    |     16|       1|      6|  8000| 128000|
| Pile des choix                     |     36|       1|      2|  5000| 180000|
| Pile de renommage des variables    |      3|       0|      1|   100|    300|
------------------------------------------------------------------------------

system

Display the rules of the system predicates defined in prolog.sys.

true

Always succeeds.

type(X, T)

Get/Check the type of X.

Possible values of T: symbol, integer, list, vector, function, var.

write(X)

Display X, with the free variables denoted by their name, the strings never surrounded by quotes.

?- X=Y, Y=f(X), Z=['text', 'more text', symbol, 100, (vector), Variable], write(X), nl, write(Y), nl, write(Z), nl.
f(f(*2))
f(f(*2))
[text, more text, symbol, 100, (vector), Variable]
[1] X = f(*1), Y = f(*1), Z = [text, more text, symbol, 100, (vector), Variable], Variable = Variable
yes

Predicates

atom(X)

Succeeds if X is a symbol.

integer(X)

Succeeds if X is an integer.

atomic(X)

Succeeds if X is a symbol or an integer.

var(X)

Succeeds if X is a variable.

list(X)

Succeeds if X is a list […].

vector(X)

Succeeds if X is a vector (…).

function(X)

Succeeds if X is a function f(…)

<(X, Y)

Succeeds if X lesser than Y.

=<(X, Y)

Succeeds if X lesser than or equal Y.

>(X, Y)

Succeeds if X greater than Y.

>=(X, Y)

Succeeds if X greater than or equal Y.

Demo

rlwrap ./prolog
Interpreteur PROLOG avec syntaxe 'Edimbourg'.
Algorithmes du PROLOG II de Marseille.

To load a file: [‘file.p’].

Types

?- type(0, T).
[1] T = integer
yes

?- type(xxx, T).
[1] T = symbol
yes

?- type('xxx', T).
[1] T = symbol
yes

?- type([], T).
[1] T = symbol
[2] T = list
yes

?- type([a,b], T).
[1] T = list
yes

?- type((), T).
[1] T = symbol
[2] T = vector
yes

?- type((a,b), T).
[1] T = vector
yes

?- type(f(a,b), T).
[1] T = function
yes

?- type(X, T).
[1] X = X, T = var
yes

Expressions

?- % The expression is evaluated
X is (14+2)^3 / (-3^4 + 2*4).
[1] X = -56
yes

?- % No evaluation when using = (unification)
Expression = solve(A*X^2 + B*X + C == 0, X).
[1] Expression = solve(==(+(*(A, ^(X, 2)), *(B, X), C), 0), X), A = A, X = X, B = B, C = C
yes

?- % no reals, just integers.
X is 3/4, Y is 4/3.
[1] X = 0, Y = 1
yes

?- halt.

Solver of the equation X+Y=Z

?- ['solver.p'].

The equation X+Y=Z is represented by plus(X,Y,Z).

By default, the domain of a free variable is 0..infinity.

When no variable is free, the equation is checked.

?- plus(0,10,10).
yes
?- plus(0,10,11).
no

When 1 variable is free, there is only 1 solution.

?- plus(0, 10, Z).
[1] Z = 10
yes
?- plus(0, Y, 10).
[1] Y = 10
yes
?- plus(X, 0, 10).
[1] X = 10
yes

When 2 variables are free, the number of solutions is infinite.

?- plus(X,10,Z).
[1] X = 0, Z = 10
[2] X = 1, Z = 11
[3] X = 2, Z = 12
...
[502] X = 501, Z = 511
[503] X = 502, Z = 512
[504] X = 503, Z = 513
Not enough memory for substitutions
Aborting current evaluation...

It’s possible to change the domain of a free argument.

?- plus([X,-100], -90, Z).
[1] X = -100, Z = -190
[2] X = -99, Z = -189
[3] X = -98, Z = -188
[4] X = -97, Z = -187
...
[501] X = 400, Z = 310
[502] X = 401, Z = 311
[503] X = 402, Z = 312
[504] X = 403, Z = 313
Not enough memory for substitutions
Aborting current evaluation...

?- plus([X,-100,-91], -90, Z).
[1] X = -100, Z = -190
[2] X = -99, Z = -189
[3] X = -98, Z = -188
[4] X = -97, Z = -187
[5] X = -96, Z = -186
[6] X = -95, Z = -185
[7] X = -94, Z = -184
[8] X = -93, Z = -183
[9] X = -92, Z = -182
[10] X = -91, Z = -181
yes

Permutations of a sequence of four elements

?- ['dif.p'].
yes
?- permutation(A,B,C,D).
[1] A = 1, B = 2, C = 3, D = 4
[2] A = 1, B = 2, C = 4, D = 3
[3] A = 1, B = 3, C = 2, D = 4
[4] A = 1, B = 3, C = 4, D = 2
[5] A = 1, B = 4, C = 2, D = 3
[6] A = 1, B = 4, C = 3, D = 2
[7] A = 2, B = 1, C = 3, D = 4
[8] A = 2, B = 1, C = 4, D = 3
[9] A = 2, B = 3, C = 1, D = 4
[10] A = 2, B = 3, C = 4, D = 1
[11] A = 2, B = 4, C = 1, D = 3
[12] A = 2, B = 4, C = 3, D = 1
[13] A = 3, B = 1, C = 2, D = 4
[14] A = 3, B = 1, C = 4, D = 2
[15] A = 3, B = 2, C = 1, D = 4
[16] A = 3, B = 2, C = 4, D = 1
[17] A = 3, B = 4, C = 1, D = 2
[18] A = 3, B = 4, C = 2, D = 1
[19] A = 4, B = 1, C = 2, D = 3
[20] A = 4, B = 1, C = 3, D = 2
[21] A = 4, B = 2, C = 1, D = 3
[22] A = 4, B = 2, C = 3, D = 1
[23] A = 4, B = 3, C = 1, D = 2
[24] A = 4, B = 3, C = 2, D = 1
yes

?- halt.

SEND + MORE = MONEY

?- ['money.p'].
Problème de cryptarithmétique :
Résoud le problème  SEND
                   +MORE
                   -----
                   MONEY
Tapez 'solution.' pour résoudre ce problème
yes
?- solution.
 9567
 1085
-----
10652

yes

?- halt.

The 8 queens problem

?- ['queens.p'].
yes
?- solution(X).
[1] X = [0, 12, 23, 29, 34, 46, 49, 59]
[2] X = [0, 13, 23, 26, 38, 43, 49, 60]
[3] X = [0, 14, 19, 29, 39, 41, 52, 58]
[4] X = [0, 14, 20, 31, 33, 43, 53, 58]
[5] X = [1, 11, 21, 31, 34, 40, 54, 60]
[6] X = [1, 12, 22, 24, 34, 47, 53, 59]
[7] X = [1, 12, 22, 27, 32, 47, 53, 58]
[8] X = [1, 13, 16, 30, 35, 47, 50, 60]
[9] X = [1, 13, 23, 26, 32, 43, 54, 60]
[10] X = [1, 14, 18, 29, 39, 44, 48, 59]
[11] X = [1, 14, 20, 31, 32, 43, 53, 58]
[12] X = [1, 15, 21, 24, 34, 44, 54, 59]
[13] X = [2, 8, 22, 28, 39, 41, 51, 61]
[14] X = [2, 12, 17, 31, 32, 46, 51, 61]
[15] X = [2, 12, 17, 31, 37, 43, 54, 56]
[16] X = [2, 12, 22, 24, 35, 41, 55, 61]
[17] X = [2, 12, 23, 27, 32, 46, 49, 61]
[18] X = [2, 13, 17, 28, 39, 40, 54, 59]
[19] X = [2, 13, 17, 30, 32, 43, 55, 60]
[20] X = [2, 13, 17, 30, 36, 40, 55, 59]
[21] X = [2, 13, 19, 24, 39, 44, 54, 57]
[22] X = [2, 13, 19, 25, 39, 44, 54, 56]
[23] X = [2, 13, 23, 24, 35, 46, 52, 57]
[24] X = [2, 13, 23, 24, 36, 46, 49, 59]
[25] X = [2, 13, 23, 25, 35, 40, 54, 60]
[26] X = [2, 14, 17, 31, 36, 40, 51, 61]
[27] X = [2, 14, 17, 31, 37, 43, 48, 60]
[28] X = [2, 15, 19, 30, 32, 45, 49, 60]
[29] X = [3, 8, 20, 31, 33, 46, 50, 61]
[30] X = [3, 8, 20, 31, 37, 42, 54, 57]
[31] X = [3, 9, 20, 31, 37, 40, 50, 62]
[32] X = [3, 9, 22, 26, 37, 47, 48, 60]
[33] X = [3, 9, 22, 26, 37, 47, 52, 56]
[34] X = [3, 9, 22, 28, 32, 47, 53, 58]
[35] X = [3, 9, 23, 28, 38, 40, 50, 61]
[36] X = [3, 9, 23, 29, 32, 42, 52, 62]
[37] X = [3, 13, 16, 28, 33, 47, 50, 62]
[38] X = [3, 13, 23, 25, 38, 40, 50, 60]
[39] X = [3, 13, 23, 26, 32, 46, 52, 57]
[40] X = [3, 14, 16, 31, 36, 41, 53, 58]
[41] X = [3, 14, 18, 31, 33, 44, 48, 61]
[42] X = [3, 14, 20, 25, 37, 40, 50, 63]
[43] X = [3, 14, 20, 26, 32, 45, 55, 57]
[44] X = [3, 15, 16, 26, 37, 41, 54, 60]
[45] X = [3, 15, 16, 28, 38, 41, 53, 58]
[46] X = [3, 15, 20, 26, 32, 46, 49, 61]
[47] X = [4, 8, 19, 29, 39, 41, 54, 58]
[48] X = [4, 8, 23, 27, 33, 46, 50, 61]
[49] X = [4, 8, 23, 29, 34, 46, 49, 59]
[50] X = [4, 9, 19, 29, 39, 42, 48, 62]
[51] X = [4, 9, 19, 30, 34, 47, 53, 56]
[52] X = [4, 9, 21, 24, 38, 43, 55, 58]
[53] X = [4, 9, 23, 24, 35, 46, 50, 61]
[54] X = [4, 10, 16, 29, 39, 41, 51, 62]
[55] X = [4, 10, 16, 30, 33, 47, 53, 59]
[56] X = [4, 10, 23, 27, 38, 40, 53, 57]
[57] X = [4, 14, 16, 26, 39, 45, 51, 57]
[58] X = [4, 14, 16, 27, 33, 47, 53, 58]
[59] X = [4, 14, 17, 27, 39, 40, 50, 61]
[60] X = [4, 14, 17, 29, 34, 40, 51, 63]
[61] X = [4, 14, 17, 29, 34, 40, 55, 59]
[62] X = [4, 14, 19, 24, 34, 47, 53, 57]
[63] X = [4, 15, 19, 24, 34, 45, 49, 62]
[64] X = [4, 15, 19, 24, 38, 41, 53, 58]
[65] X = [5, 8, 20, 25, 39, 42, 54, 59]
[66] X = [5, 9, 22, 24, 34, 44, 55, 59]
[67] X = [5, 9, 22, 24, 35, 47, 52, 58]
[68] X = [5, 10, 16, 30, 36, 47, 49, 59]
[69] X = [5, 10, 16, 31, 35, 41, 54, 60]
[70] X = [5, 10, 16, 31, 36, 41, 51, 62]
[71] X = [5, 10, 20, 30, 32, 43, 49, 63]
[72] X = [5, 10, 20, 31, 32, 43, 49, 62]
[73] X = [5, 10, 22, 25, 35, 47, 48, 60]
[74] X = [5, 10, 22, 25, 39, 44, 48, 59]
[75] X = [5, 10, 22, 27, 32, 47, 49, 60]
[76] X = [5, 11, 16, 28, 39, 41, 54, 58]
[77] X = [5, 11, 17, 31, 36, 46, 48, 58]
[78] X = [5, 11, 22, 24, 34, 44, 49, 63]
[79] X = [5, 11, 22, 24, 39, 41, 52, 58]
[80] X = [5, 15, 17, 27, 32, 46, 52, 58]
[81] X = [6, 8, 18, 31, 37, 43, 49, 60]
[82] X = [6, 9, 19, 24, 39, 44, 50, 61]
[83] X = [6, 9, 21, 26, 32, 43, 55, 60]
[84] X = [6, 10, 16, 29, 39, 44, 49, 59]
[85] X = [6, 10, 23, 25, 36, 40, 53, 59]
[86] X = [6, 11, 17, 28, 39, 40, 50, 61]
[87] X = [6, 11, 17, 31, 37, 40, 50, 60]
[88] X = [6, 12, 18, 24, 37, 47, 49, 59]
[89] X = [7, 9, 19, 24, 38, 44, 50, 61]
[90] X = [7, 9, 20, 26, 32, 46, 51, 61]
[91] X = [7, 10, 16, 29, 33, 44, 54, 59]
[92] X = [7, 11, 16, 26, 37, 41, 54, 60]
yes

?- halt.

Unification

?- ['unificat.p'].
yes

% Ce programme ne comprend qu'une seule unification : U = V.
% Alors que dans PROLOG II le temps est raisonnable, pour beaucoup de PROLOG
% il faut des dizaines de minutes pour faire cette unification avec
% test([1,2,3,4,5,6,7,8,9,10]).

% Si test(L) avec L liste de n éléments alors :
%   U va être un arbre de 8^n feuilles, idem pour V.
%   Donc : n=0  ==>                      1 unification.
%          n=1  ==> 8^1   =              8 unifications.
%          n=2  ==> 8^2   =             64 unifications.
%          n=3  ==> 8^3   =            512 unifications.
%          n=4  ==> 8^4   =          4 096 unifications.
%          n=5  ==> 8^5   =         32 768 unifications.
%          n=6  ==> 8^6   =        262 144 unifications.
%          n=7  ==> 8^7   =      2 097 152 unifications.
%          n=8  ==> 8^8   =     16 777 216 unifications.
%          n=9  ==> 8^9   =    134 217 728 unifications.
%          n=10 ==> 8^10  =  1 073 741 824 unifications.
%          etc...

:- echo(off).
yes
?- test([1,2,3,4,5,6,7,8,9,10]).
Je commence l'unification...
J'ai fini !
yes

?- halt.
